Vacuum drying ovens enterprises Application:
Drying, baking, melting and sterilization in the labs.
Vacuum drying ovens enterprises Product features:
Accurate: intelligent temperature controller with fuzzy-PID,temperature control is precise and reliable;
Rapid: with fast warming and forced convection, the hot air can kill microorganism directly and quickly ;
Safe: Independent protections of over-temperature, overcurrent, electric leakage and short-circuit. Assure your experiment safety.
Convenient: the loading plates can be cleaned in the box, convenient for routine maintenance and operation.
Vacuum drying ovens enterprises Technical parameters:
| 9013A | 9023A | 9053A | 9073A | 9123A | 9203A | |
| Source voltage | AC(220±22)V (50±1)HZ | |||||
| Temp-range | RT+10~280℃ | |||||
| Temp-resolution | 0.1℃ | |||||
| Temp-stability | ±1.0℃ | |||||
| Power(W) | 550W | 800W | 850W | 1100W | 1550W | 2050W |
| Timing range | (1~9999)min | |||||
| Inner size(mm ) | 250*260*250 | 340*330*320 | 420*350*390 | 450*400*450 | 550*450*550 | 600*595*650 |
| Outline size(mm ) | 530*480*430 | 620*540*490 | 710*610*520 | 735*625*620 | 830*650*715 | 880*795*820 |
| Volume | 10L | 20L | 50L | 70L | 136L | 220L |
| Loading plate | 2pcs | |||||
| 9030A | 9050A | 9070A | 9140A | 9240A | 9420A | 9620A | |
| Source voltage | AC(220±22)V (50±1)HZ | AC(380±38)V (50±1)HZ | |||||
| Temp-range | RT+10~250℃ | ||||||
| Temp-resolution | 0.1℃ | ||||||
| Temp-stability | ±1.0℃ | ||||||
| Power(W) | 800W | 850W | 1100W | 1550W | 2050W | 3500W | 4000W |
| Timing range | (1~9999)min | ||||||
| Inner size(mm ) | 340*330*
320 |
420*350*390 | 450*400*450 | 550*450*550 | 595*595*650 | 600*550*1300 | 800*640*1270 |
| Outline size(mm ) | 625*530*
490 |
710*610*520 | 735*625*620 | 830*650*715 | 880*790*815 | 780*750*1880 | 1030*840*1770 |
| Volume | 30L | 50L | 80L | 136L | 220L | 420L | 620L |
| Loading plate | 2pcs | 3pcs | 4pcs | ||||
| 9035A | 9055A | 9075A | 9145A | 9245A | |
| Source voltage | (220±22)V (50±1)HZ | ||||
| Temp-range | RT+10℃~300℃ | ||||
| Temp-resolution | 0.1℃ | ||||
| Temp-stability | ±1.0℃ | ||||
| Power(W) | 850W | 1100W | 1550W | 2050W | 2450W |
| Timing range | (1~9999)min | ||||
| Inner size(mm ) | 340*320*320 | 420*395*350 | 450*400*450 | 550*450*550 | 650*650*800 |
| Outline size(mm ) | 620*530*490 | 720*590*520 | 740*618*630 | 830*650*715 | 940*795*990 |
| Loading plate | 2pcs | ||||
