Thermal shock test chamber
Introduction:Thermal Shock Test chamber used to test the material structure or composite material in an
instant by the extremely high temperatures and very low temperature continuous environment which can
endure the degree of order in the shortest possible time to test its thermal expansion and contraction
caused by chemical changes physical harm. The applicable the object material, including metals, plastics,
rubber, electronic, …, etc., can be used as the basis of its product improvement or reference.
Thermal shock test chamber
Specifications:
| Model | XB-OTS-50 | XB-OTS-80 | XB-OTS-150 | XB-OTS-225 | XB-OTS-408 |
| Inner size WxHxD(cm) | 36×40×35 | 40×50×40 | 50×60×50 | 60×75×50 | 80×85×60 |
| External size WxHxD(cm) | 138x180x155 | 150X190X160 | 190x200X195 | 210x220X205 | 225x250x220 |
| Shock Temperature ragne | -65°C~150°C | ||||
| Heating up time | RT~200°C about 35min | ||||
| Cooling down time | RT~-70°C about 75min | ||||
| Temp recover time/change time | ≤5min / ≤10sec | ||||
| Temp control accuracy/
distribution accuracy |
±0.5°C / ±2.0°C | ||||
| Inner materials | SUS 304# stainless steel plate for inner chamber,and stainless steel plate
+ spray painting for external chamber. |
||||
| Insulation materials | High-temperature high-density amino acid ethyl ester foam insulator material. | ||||
| Systems | P.I.D+S.S.R+Microcomputer balanced temperature control system. | ||||
| Cooling systems | Semi-hermetic two-stage compressor (water-cooled) /
hermetic two-stage compressor (air-cooled). |
||||
| Safety devices | Fuse switch, high and low pressure protection switch compressors,
refrigerant pressure protection switch failure warning system, electronic siren. |
||||
| Fitting | Outlook window (special purchase), the upper and lower adjustable compartment
two energized measured line hole, casters,level bracket. |
||||
| Power | 3 phase AC380V 50HZ/60HZ | ||||
| Controller | Taiwan TATO | ||||
| Compressor | Germany Bitzer Brand | ||||
